NON-LOCKING PLATING SYSTEM

Cloverleaf Plate, 3.5 mm

Specifications:

Features

  • Buttress plate allows good fit on the medial aspect of distal tibia
  • Thin and can easily be cut
  • The plate has a frontal wing which allows fixation to the medial malleolus
  • Oblong hole allows for temporary fixation of the plate prior to final adjustment and fixation
  • Head holes suitable for 4.0 mm cancellous screws
  • Shaft compression screws suitable for 3.5 mm cortex screws
  • Available in both Titanium and Stainless Steel

Profile

  • Thickness (T): 2 mm
  • Width (W): 15.2 mm
  • Hole Spacing (HS): 16 mm

Cloverleaf Plate

No. of Holes CODE
S.S. Titanium
3 608.03 608.03T
4 608.04 608.04T
5 608.05 608.05T
6 608.06 608.06T
7 608.07 608.07T
8 608.08 608.08T
9 608.09 608.09T
10 608.10 608.10T
11 608.11 608.11T
12 608.12 608.12T
13 608.13 608.13T
14 608.14 608.14T
