Specifications:
| Thread Dia. | 4.0mm |
| Drill Bit for Threaded Hole | 6.0 mm |
| Shaft Dia. | 1.9 mm |
| Core Dia. | 10 – 60 mm (2 mm Diff) |
| Hexagonal Socket Width | 2.5 mm |
| Head Dia. | Fully threaded |
| CODE | LENGTH (mm) | |
| S.S. | Titanium | |
| 724.10 | 724.10T | 10mm |
| 724.12 | 724.12T | 12mm |
| 724.14 | 724.14T | 14mm |
| 724.16 | 724.16T | 16mm |
| 724.18 | 724.18T | 18mm |
| 724.20 | 724.20T | 20mm |
| 724.22 | 724.22T | 22mm |
| 724.24 | 724.24T | 24mm |
| 724.26 | 724.26T | 26mm |
| 724.28 | 724.28T | 28mm |
| 724.30 | 724.30T | 30mm |
| 724.32 | 724.32T | 32mm |
| 724.34 | 724.34T | 34mm |
| 724.36 | 724.36T | 36mm |
| 724.38 | 724.38T | 38mm |
| 724.40 | 724.40T | 40mm |
| 724.45 | 724.45T | 45mm |
| 724.50 | 724.50T | 50mm |
| 724.55 | 724.55T | 55mm |
| 724.60 | 724.60T | 60mm |
